Single Phase Overhead Pole Mounted Distribution Transformer

2-YEARS WARRANTY

Our sales manager Grace with 10-years distribution transformer exporter experience

Will Help You Make Technical Solutions and Shipment Solutions

Contact Grace Now!

Introduction of Single Phase Overhead Pole Mounted Distribution Transformer:

The capacities of single phase distribution transformers are 5, 10, 15, 25, 37.5, 50, 75, 100, 167, 250, 333kVA

The high voltage rated voltage is 7620V (7200V), when three single-phase transformers are used in Y wiring, the line voltage is 13200V (12470V); the low voltage rated voltage is 120/240V (or 240/480V), when the low voltage is connected in series It can provide 240V (or 480V) when the low voltage is connected in parallel, and can provide 120V (or 240V) when the low voltage is connected in parallel. According to the needs, the high voltage can have a tap voltage of ±2×2.5% of the rated voltage.

Features of Single Phase Overhead Pole Mounted Distribution Transformer:

The single phase overhead distribution transformers is simple in structure, small in size and low in loss, mainly due to small iron loss, and is suitable for application and promotion in low-voltage distribution networks with small load density.

Application of Single Phase Overhead Pole Mounted Distribution Transformer:

Single phase pole mounted transformers are small transformers designed for use in areas with a grid frequency of 60Hz such as the United States, Canada and the Philippines. They can be used as lighting power sources in residential or commercial areas or as power sources for equipment.

Conditions of use for Single Phase Overhead Pole Mounted Distribution Transformer:

The altitude does not exceed 1000m outdoors or outdoors

Maximum ambient temperature +40℃

Maximum daily average temperature +30℃

Maximum annual average temperature +20℃

Minimum temperature -25℃

Transformers operating under special conditions of use can be provided according to user requirements

Parameters Of Single Phase Overhead Pole Mounted Distribution Transformer：

Packaging & Shipping
